VS-AXESS-4ETL Access Control Panel

Category: Access Control

The VS-AXESS-4ETL is a powerful, reliable, and stable access controller for 4 doors. This system can connect up to 4 door magnetic inputs, 4 door switch inputs, and 4 card readers (wiegand interface). The uplink and downlink adopt TCP/IP while wiegand communicates respectively. Its signal is processed with special encryption and can be run offline. Anti-tampering function is also supported. You have the capability of up to 10,000 users for the system as well. An incredible feature of this system is all the different card types supported. You have normal, disabled, blacklist, patrol, visitor, duress, super card, etc. These can all be monitored and set up with your own custom notifications for each. Speaking of notifications, the panel includes tamper-proof alarm for card reader, unsecured door alarm, forced entry door alarm, alarm for door opening timeout, duress alarm, and alarm for invalid card swiping attempts alarm. You can also set up an insufficient storage alarm for offline event, network break alarm. You need to add more doors? Not a problem! You can purchase another panel for the necessary number of doors (1 door panel, 2 door panel, 4 door panel) and connect it to your current system. The software will integrate the new doors with your current doors and you are all set.

Description

The VS-AXESS-4ETL is a powerful, reliable, and stable access controller for 4 doors. This system can connect up to 4 door magnetic inputs, 4 door switch inputs, and 4 card readers (wiegand interface). The uplink and downlink adopt TCP/IP while wiegand communicates respectively. Its signal is processed with special encryption and can be run offline. Anti-tampering function is also supported. You have the capability of up to 10,000 users for the system as well. An incredible feature of this system is all the different card types supported. You have normal, disabled, blacklist, patrol, visitor, duress, super card, etc. These can all be monitored and set up with your own custom notifications for each. Speaking of notifications, the panel includes tamper-proof alarm for card reader, unsecured door alarm, forced entry door alarm, alarm for door opening timeout, duress alarm, and alarm for invalid card swiping attempts alarm. You can also set up an insufficient storage alarm for offline event, network break alarm. You need to add more doors? Not a problem! You can purchase another panel for the necessary number of doors (1 door panel, 2 door panel, 4 door panel) and connect it to your current system. The software will integrate the new doors with your current doors and you are all set.

Specification

Working Voltage DC 12V
Power consumption ?3.5W (without load)
Processor 32-bit
Uplink Communication Interface TCP/IP Network Interface and RS-485 Interface
Downlink Communication Interface Wiegand interface
Storage Storage for 10.000 valid cards information and 50.000 card swiping records
LED Indicator Power Supply Status, Communication Status, Abnormal Status
Built-in Clock Yes
Accessible Card Reader 4 Card Readers (Wiegand Interface) Connectable
Input Interface Door Magnetic4, Door Switch4, Case Input4
Output Interface Door Switch Relay4, Alarm Relay4
Working Temperature -20C to +65C (-4F~+149F)
Working Humidity 10% to 90% (Non-Condensing)
Dimensions (LWH) 285(L) x 237(W) x 69(H)mm 11.22(L) x 9.33(W) x 2.71(H)in.
